Modular Prefabricated House Manufacturer Philippines

The company supplies and installs concrete precast components for perimeter fence construction all over Mindanao whether if its residential, commercial, industrial or agricultural fence. We also construct residential houses using our products. The concrete precast components substitute

s the conventional hollow blocks but more stronger, easier and faster to install and it comes with a aesthetic design.

Products

MPSI Component Fencing System

Prefabricated Wall Panels

BBD Panel: 2000mm X 500mm X 40mm

Solid Panel Back-to-Back Design
Strength = 2,500 Pounds per Square Inch (PSI)
Smooth Finish paint ready
Fully reinforced: 4Ver X 4Hor 5mm Ø Main Bar

Prefabricated Column

ICT Column: 130mm X 160mm

Height range from 2.4 to 4.5M
Strength = 2,500 Pounds per Square Inch (PSI)
Strength = 3000 Pounds per Square Inch (PSI)
Smooth Finished
3/4/5 Vert Bar Reinforced

Plinth Footing

430mm2 Base X 400 mm HGT

Strength = 2500 Pounds per Square Inch (PSI)
Reinforced by 4-8mm Ø Ver Bar and 4-8mm Ø Bottom B.W.

Tie Beam

100mm X 130mm

2.0M Span
Strength = 2500 Pounds per Square Inch (PSI)
Reinforced by 4-10mm Ø Main Bars
Smooth Finished Paint Ready

The System can be used for the following:

Housing
Classrooms
Perimeter Fencing
Smooth Finished Paint Ready

Advantages:

Easy to build… Expandable… Transferable
No heavy Equipment to use
Minimum labor force required – average of 6 manpower for a 36 sq. m. house
2500 PSI vs. CHB at 300-900 PSI
Fireproof and termite-proof
Earthquake simulated tested exceeding the Phil. Building Code requirement
More livable space, for every 20sqm. Footprint = additional 1sqm. of livable space
Smooth finish for BBD panel – no need for plastering
Manufactured in a quality-controlled environment
